Touring Terrain

On-road caravans built for bitumen.

Touring Terrain · On-road

Touring Terrain is the on-road half of the range. 4 layouts, 20'6–23', on a PVC frame with running gear tuned for bitumen.

Every Network RV leaves one line in Campbellfield, Melbourne: a 150 mm Permagal chassis, 315 Ah of lithium, 400 W of solar and 2,265 mm of internal width, whichever range it sits in.

View layouts
From the build sheet

Figures are 2027 master build-sheet values for the standard build of the nominated layout and vary with the options fitted. Weights publish per layout once confirmed with engineering. Payload is not a recommendation to carry that weight: load distribution and tow ball download apply as well.

Layouts

Pick the floor you'll live on.

Touring Terrain Wide Bunk floorplan
Touring Terrain · NRV2060WB

20'6 Wide Bunk

Touring Terrain from $94,125 This layout’s price is with the dealer

Front island bed with robes both sides, mid kitchen and dinette, rear double bunk on the offside with the bathroom and wall-mounted washer opposite.

Sleeps
4
Bed
Front island, 1500 x 1900mm
Bunks
Wide Bunks
Bathroom
Ensuite
Axle
Tandem
Internal length
6,335 mm
Enquire about the 20'6 Wide Bunk
20'6 Wide Bunk selected
The six systems

Three change with the range. Three never do.

Wall system0timber

A PVC frame carries Alucomp composite cladding on the front, rear and sides, capped with a one-piece fibreglass roof.

See it in the numbers
Touring Terrain caravan, studio side, PVC frame and Alucomp wall
Wall system0timber

A PVC frame carries Alucomp composite cladding on the front, rear and sides, capped with a one-piece fibreglass roof.

See it in the numbers
Wall system, 0 timber
Certainty · included with every new van

12 months of Club Camplify

RV protection, CMCA membership and discounts across 100+ partner brands, included with every new Network RV from a participating Australian dealer.

Separate from your Network RV warranty. It does not replace or extend it. Runs for 12 months from handover, then continues only if you choose.
RV protection
MyWay Protect, a discretionary risk product issued by MyWay Mutual Holdings Limited. It is not insurance, and benefits are paid at the discretion of the mutual's board.
12 MO
CMCA membership
Campervan and Motorhome Club of Australia, full member benefits.
12 MO
Partner discounts
Parks, gear and services across the Club Camplify partner network.
100+
Club Camplify is a membership provided by Camplify Co (Australia) Pty Ltd (ACN 603 217 287), authorised representative 1314751 of Regis Licensing Pty Ltd (AFSL 338156). It is not a contract of insurance, and it is separate from the Network RV warranty. An excess applies. This does not limit any rights you have under the law that cannot be excluded. Read the full terms.
Off-grid

How long the 20'6 Wide Bunk keeps you off-grid

Free camping with two of you, this layout runs 5 nights before fresh water stops you.

Fresh110 L4.6 nights
Grey110 L6.4 nights
Battery315 AhSolar keeps up at this load
Solar400 W1.22 kWh a day
How you'd actually travel
Where you're stayingNo tap, no power, no dump point
How many of youThe biggest single driver of water
2
ShowersQuick showers
Sun4.5 peak sun hours · typical touring sun
Air conditioner overnightAbout 1.2 kW while it runs
Washing machineAround 40 L a load
How this is worked out
Water used a day24 L
Reaching the grey tank17 L
Power drawn a day0.75 kWh
Solar generated a day1.22 kWh
Usable battery3.4 kWh
What runs out, and when
Fresh water110 L4.6 nights
Grey tank110 L · TBC6.4 nights
Battery315 Ah · 400 WSolar keeps up

014 nights

Fresh water is the limit: 110 L at about 24 L a day, which is where two of you and quick showers land.

On board as standard
Fresh water110 L
Grey water110 L · to confirm
Battery315 Ah lithium
Solar2 × 200 W
Gas2 × 9 kg
Fresh water full, as payload110 kg

How these figures are worked out. Fresh water at about 12 litres per person a day with a quick shower each, of which roughly 72 per cent reaches the grey tank. Power at 0.75 kWh a day for the fridge, lights, pumps and charging, against solar rated at 68 per cent of its panel figure to allow for a flat roof, controller losses and heat. Usable battery at 90 per cent of the nameplate capacity. Change any setting above and the arithmetic follows it.

These are planning estimates for the standard build of this layout, before options and accessories. They are not measured figures and they are not a performance guarantee. Real duration varies with the weather, how the van is used, how full the tanks are when you leave and how you like to travel.

Water is payload. A full fresh tank is 110kg you cannot also spend on gear, and payload is a legal limit set by your caravan's compliance plate rather than a target. The weights for this layout are in the build sheet below. Never exceed the ATM, GTM or tow ball limit shown on the compliance plate, and check your loaded weights at a licensed public weighbridge before you tow.

Running the air conditioner overnight is not achievable on battery alone on any build in this range. It needs mains power or a generator, and the worksheet above shows what it costs you.

Fitted as standard

Same spec, every layout in the range.

The figures buyers compare, straight off the 2027 build sheet. Switch to both ranges and only the rows that change stay in ink.

Weights · per layout
ATM3,500 kg3,500 kg
Tare2,427–2,758 kg2,386–2,455 kg
Ball weight123–189 kg150–168 kg
Power and water
Battery1 × 315 Ah lithium · metal box on chassis1 × 315 Ah lithium · metal box on chassis
Solar2 × 200 W2 × 200 W
Water tanks1 × 110 L + greywater2 × 110 L + greywater
Running gear
Chassis150 mm Permagal, painted black150 mm Permagal, painted black
SuspensionRoller Rocker · 3,500 kg tandemAL-KO Enduro X · 3,500 kg tandem
CouplingStandardDO35
Wheels and tyres15″ Showstar MFB · 235 Terratrack16″ Attack U4B · 265 Tracmax MT
Body and living
Wall systemPVC frame · Alucomp panelComposite sandwich panel
RoofOne-piece fibreglassComposite sandwich panel
Internal width2,265 mm2,265 mm
FridgeDometic RCD10.5XES compressor · 200 LDometic RCD10.5XES compressor · 200 L

11 of 85 standard items · 6 differ on the other range

Touring Terrain · 2027 master specification

The full build sheet

85 items fitted before you choose a single option

Chassis 14 items

7 differ on Terrain Tuff
Chassis150 mm Permagal, painted black
A-frame150 mm, extended 350 mm
Riser50 mm at axleTerrain Tuff · —
SuspensionRoller Rocker · 3,500 kg tandemTerrain Tuff · AL-KO Enduro X · 3,500 kg tandem
Suspension, single axleRoller Rocker · 2,500 kgTerrain Tuff · AL-KO Enduro X · 2,800 kg
Brakes12″
Wheels and tyres15″ Showstar MFB · 235 TerratrackTerrain Tuff · 16″ Attack U4B · 265 Tracmax MT
CouplingStandardTerrain Tuff · DO35
Bumper bar2 armTerrain Tuff · 4 arm
Spare wheel1, bolted to bumper bar
Water tanks1 × 110 L + greywaterTerrain Tuff · 2 × 110 L + greywater
Gas bottles2 × 9 kg
Pull-out stepSteel, single
Wheel box150 mm

External 15 items

5 differ on Terrain Tuff
Wall systemPVC frame · Alucomp panelTerrain Tuff · Composite sandwich panel
RoofOne-piece fibreglassTerrain Tuff · Composite sandwich panel
InsulationFull
Side windowsRanger, aluminium frame
Main doorRanger 1850 × 622, black
Boot doorBlack flat plate · 450 × 1524Terrain Tuff · Black chequer plate · 450 × 1524
Pebble guardBlack flat plate
Side plateBlack flat plate · 600 mm
Rear plateBlack flat plate
Roof hatch1 × Dometic mini skylight · 400 × 400
Power hatches1 × Ranger 12 V · 324 × 324Terrain Tuff · 2 × Ranger 12 V · 324 × 324
Pressure hatchMilenco dust-reduction
Picnic tableRanger 800 × 450, black
AwningDometic 8700 Granite · 16′
Tunnel boot2 × 572 × 507
External shower—Terrain Tuff · Fitted

Appliances 10 items

identical on both ranges
StoveSwift Mini-Grill · 3 gas, 1 electric, grill
RangehoodRanger 12 V, flush mount
MicrowaveFitted
FridgeDometic RCD10.5XES compressor · 200 L
Air conditionerNCE Gree 3.5 kW inverter
Washing machine3.2 kg top loader
AudioCD/radio head unit
Internal speakers2
External speakers2
TV24″ smart TV supplied · provision wired

Electrical 20 items

2 differ on Terrain Tuff
Battery1 × 315 Ah lithium · metal box on chassis
Solar2 × 200 W
Battery charger—
Annexe lights2 × 200 mm dual-colour LEDTerrain Tuff · 3 × 200 mm dual-colour LED
Door lightIn entry handle
External power points1 × 240 V · 1 × 12 V
Car plug12-pin flat
Anderson plugs2 · A-frame and roadside
Roof antennaMilenco dust-reduction
External lightsLED
Internal lightsLED
Reversing cameraSafety Dave, wired full kit
External TV1 × TV pointTerrain Tuff · TV box
Breakaway systemElectric, standard
Fan1 × 12 V, bedroom
Kitchen lightLED, framed
Overhead cupboard lightingLED strip, each cupboard
Tail lightsLED rear combination lamps
Wireless phone chargersOne per bedside
Reading lightsBlack, with USB
Tunnel boot lightLED, door side

Plumbing 13 items

identical on both ranges
Hot waterSwift instant gas
ShowerRectangular, black tapware
ToiletDometic cassette
Sink tapBlack mixer
SinkBlack oval with drainer
En-suite basinNCE 385 mm, black and white
En-suite tapBlack, tall
Water pump12 V
Water fillers2 × lockable
Water gauge3-tank LED level indicator
External tapOn A-frame
Gas bayonetFitted
Grey water tankFitted

Furniture and finish 6 items

identical on both ranges

Benchtop, splashback, floor, upholstery, door style and decal are chosen at order from the Network RV palette.

Wall plyWhite
En-suite wall plyWhite
Furniture carcassWhite
Bed headFull height
J-mould insertBlack
Door hingesStandard, recessed

Hardware and finishing 7 items

identical on both ranges
MattressPillow top
Main door blindBlack
Entry grab handleBlack
Shower screenBlack frame, clear glass
Towel railBlack
Toilet paper holderBlack
Bathroom mirrorLED

Family layouts

identical on both ranges

Fitted on bunk layouts only. Not counted in the standard total.

FansBunk fans
Bunk mattressesFitted
Magazine pocketsFitted
Bed headsFitted

Weights

identical on both ranges

Ranges across Touring Terrain layouts with confirmed weights. Your selected layout's payload and ATM show in the summary above.

ATM3,500 kg
Tare2,427–2,758 kg
Ball weight123–189 kg
Warranty · three years, both rangesThree years' manufacturer's warranty on every new Network RV, from delivery to its first owner. Your Australian Consumer Law guarantees cannot be excluded and apply in addition. Read the full terms
